Overview
The LM2904A/2902A series amplifiers are newest high supply voltage amplifiers with low offset, low power and stable frequency response. They incorporate 3PEAK’s proprietary and patented design techniques to achieve very good AC performance with 0.9MHz bandwidth, 0.5V/μs slew rate and maximum 3mV offset while drawing only 100μA of quiescent current per amplifier. The input common-mode voltage range extends to V–, and the outputs swing rail-to-rail. The LM2904A/2902A family can be used as plug-in replacements for many commercially available op-amps to reduce power and improve input/output range and performance.
The combination of features makes the LM2904A/2902A ideal choices for power module, industrial control, motor control and audio application.
-
Status
Production
-
Rating
Industrial
-
Channel
2
-
Supply Voltage (Min)
3
-
Supply Voltage (Max)
36
-
Iq per channel (Max) (μA)
200
-
GBW (Typ) (MHz)
0.9
-
Slew Rate (Typ) (V/μs)
0.5
-
Rail-Rail In
No, to V- only
-
Rail-Rail Out
Yes
-
Ishort (Typ) (mA)
30
-
Vos (Max) (mV)
3
-
Offset Drift (Typ) (μV/°C)
7
-
Ib (typ) (pA)
60
-
Vn (Typ) (nV/rtHz)
70
-
Peak Noise at 0.1 to 10Hz (μVpp)
20
-
Shutdown/Disable
/
-
Operating Temperature Range (°C)
-40 to 125
-
Feature
/
-
Package
SOP8, TSSOP8, MSOP8
Development Resources
-
Documentation
-
Show FilterHidden FilterDocumentation
-
Data Sheet
-
Selection Guide
-
Application Note
-
Technical Note
-
User Guide
-
Test Report
- Document Name
- Type
- Language
- Date
-
Data SheetEnglish02/02/2024
36V General Purpose Op Amps
-
Technical NoteEnglish01/19/2024
-
Technical NoteEnglish01/19/2024
-
Technical NoteEnglish01/19/2024
-
Selection GuideEnglish01/19/2024
-
Application
• Power Module
• Sensor Interface
• Motor Control
• Audio
Ordering Detail
| Order Part Number | Buy | Samples | Rating | Feature | Status | 1ku Price | Release Date | Package | Lead time (week) | MSL | Packing | MPQ | CPQ |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| LM2904A-SR | Industrial Grade | / | Released | $0.054 | 2018-07-02 | SOP8 | 9 | MSL3 | T&R | 4000 | 20000 | ||
| LM2904A-VR | Industrial Grade | / | Released | $0.054 | 2019-01-28 | MSOP8 | 10 | MSL3 | T&R | 3000 | 15000 | ||
| LM2904A-TSR | Industrial Grade | / | Released | $0.054 | 2019-01-28 | TSSOP8 | 11 | MSL3 | T&R | 3000 | 15000 | ||
| LM2904A-SO1R-S | AEC-Q100 | / | Released | $0.129 | 2022-11-18 | SOP8 | 10 | MSL3 | T&R | 4000 | 20000 | ||
| LM2904A-VS1R-S | AEC-Q100 | / | Released | $0.074 | 2023-05-06 | MSOP8 | 10 | MSL3 | T&R | 3000 | 15000 | ||
| LM2904A-TS1R-S | AEC-Q100 | / | Released | $0.074 | 2023-04-28 | TSSOP8 | 11 | MSL3 | T&R | 3000 | 15000 |
Note: All sample requests must be approved through your 3PEAK sample account, click the request sample button to log in or create your account.
Please allow 1 business day for processing time.
