Overview
The TPW4425 is a four channel single-pole dual-throw analog switch (SPDT) suitable for use in analog or multiplexer/demultiplexer applications.
The device is designed on an enhanced process that provides lower power dissipation yet gives high switching speeds. These devices can operate equally well as either multiplexers or demultiplexers and have an input range that extends to the supplies. All channels exhibit break-before-make switching action, preventing momentary shorting when switching channels.
-
Status
Production
-
Rating
Industrial
-
Channel
4
-
Switch Config
2:1
-
VCC-VEE (Min) (V)
3
-
VCC-VEE (Max) (V)
16
-
VCC (Min) (V)
3
-
VCC (Max) (V)
16
-
VEE (Min) (V)
-8
-
VEE (Max) (V)
0
-
Input Range
VEE to VDD
-
BW (MHz)
150
-
IQ (μA)
0.1
-
Ron (Ω)
4
-
Leakage Current (nA)
100
-
VIH (Min) (V)
1.5
-
VIL (Max) (V)
0.5
-
tON (ns)
320
-
tOFF (ns)
130
-
Package
QFN4X4-20
Development Resources
-
Documentation
-
Show FilterHidden FilterDocumentation
-
Data Sheet
-
Selection Guide
-
Application Note
-
Technical Note
-
User Guide
-
Test Report
- Document Name
- Type
- Language
- Date
-
Data SheetEnglish02/02/2024
16V General Purpose Analog Switch
-
Technical NoteEnglish01/19/2024
-
Technical NoteEnglish01/19/2024
-
Technical NoteEnglish01/19/2024
-
Selection GuideEnglish01/19/2024
-
Application
• Industry control systems
• Battery-powered systems
• Audio Signal Routing
• Instrumentation
Ordering Detail
| Order Part Number | Buy | Samples | Rating | Feature | Status | 1ku Price | Release Date | Package | Lead time (week) | MSL | Packing | MPQ | CPQ |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| TPW4425-QFKR-S | Industrial Grade | / | Production | $1.656 | 2021-11-17 | QFN4X4-20 | 10 | MSL3 | T&R | 3000 | 15000 |
Note: All sample requests must be approved through your 3PEAK sample account, click the request sample button to log in or create your account.
Please allow 1 business day for processing time.
